PK223DM
2.2 W/m*K
Fast Curing in room temperature
Thermal Gap Filler PK223DM is a gel designed to fill gaps between electronic components to enhance heat dissipation efficiency. It can cure at room temperature or high temperatures. Compared to thermal pads, this two-part thermal gap filler not only applies low stress to components, offers high thermal conductivity, and low viscosity, but also maintains insulation properties. It is an ideal gap-filling material for use with LiPOLY's dedicated putty intelligent dispenser, making it suitable for automated dispensing production lines.

CATEGORY

Thermal Putty

FEATURES

/ Thermal conductivity: 2.2 W/m*K
/ Fast curing in normal atmospheric temperature
/ Great reliability
/ Great sealing in low pressure

CONFIGURATIONS

/ Cartridges: 50ml, 400ml
/ Other special and custom sizes are available upon request

TYPICAL APPLICATION

/ Between CPU and heat sink
/ Between a component and heat sink
/ Power supplies
/ High speed mass storage drives
/ Telecommunication hardware
/ Electric vehicle& Automotive battery
/ 5G base station & infrastructure
/ EV electric vehicle

TYPICAL PROPERTIES

PROPERTY PK223DM UNIT TEST METHOD
Color White-A Gray-B - Visual
Solid content Two-part : 100:100 - -
Viscosity A 120 Pa.s ISO 3219
Viscosity B 110 Pa.s ISO 3219
Density 2.2 g/cm³ ASTM D792
Shelf life 24 months - -
Hardness (AFTER CURE) 50 Shore OO ASTM D2240
ROHS & REACH Compliant - -
THERMAL
Thermal conductivity 2.2 W/m*K ASTM D5470
Thermal impedance@10mils BLT 0.294 °C-in²/ W ASTM D5470
Thermal impedance@30mils BLT 0.710 °C-in²/ W ASTM D5470
