Lightweight thermal putty is a low-density, lightweight thermal material commonly used in lightweight drones and EV (electric vehicle) components. For lightweight drones, reducing weight can directly extend flight endurance, as battery weight accounts for a large proportion; lowering the weight effectively improves the endurance per unit of electrical energy. In electric vehicles, lightweight design also reduces energy consumption and increases battery range.
Lightweight thermal putty is a low-density, lightweight thermal material commonly used in lightweight drones and EV (electric vehicle) components. For lightweight drones, reducing weight can directly extend flight endurance, as battery weight accounts for a large proportion; lowering the weight effectively improves the endurance per unit of electrical energy. In electric vehicles, lightweight design also reduces energy consumption and increases battery range.
Lightweight thermal putty is a low-density, lightweight thermal material commonly used in lightweight drones and EV (electric vehicle) components. For lightweight drones, reducing weight can directly extend flight endurance, as battery weight accounts for a large proportion; lowering the weight effectively improves the endurance per unit of electrical energy. In electric vehicles, lightweight design also reduces energy consumption and increases battery range.
Lightweight thermal putty is a low-density, lightweight thermal material commonly used in lightweight drones and EV (electric vehicle) components. For lightweight drones, reducing weight can directly extend flight endurance, as battery weight accounts for a large proportion; lowering the weight effectively improves the endurance per unit of electrical energy. In electric vehicles, lightweight design also reduces energy consumption and increases battery range.

——

DTT13-s
13.0 W/m*K
No Vertical Flow
Lightweight thermal putty is a low-density, lightweight thermal material commonly used in lightweight drones and EV (electric vehicle) components. For lightweight drones, reducing weight can directly extend flight endurance, as battery weight accounts for a large proportion; lowering the weight effectively improves the endurance per unit of electrical energy. In electric vehicles, lightweight design also reduces energy consumption and increases battery range.
Datasheet Download

CATEGORY

Thermal Putty

FEATURES

/ Thermal conductivity:13.0 W/m*K
/ Bond line thickness:200-3000µm
/ Designed to remove manufacturing tolerances
/ Does not produce stress on delicate components
/ No vertical flow
/ Dispensable for serial manufacture
/ For any high compression andlow stress application

VERTICAL RELIABILITY

Using 3.0mm pad as a gap control, put the putty between the aluminum and the glass panel mark the initial position. Then, place it in the oven with 125℃ for 1,000 hours and observe itsdisplacement after reliability test

TYPICAL APPLICATION

/ Between CPU and heat sink
/ Between a component and heat sink
/ High speed mass storage drives
/ Telecommunication hardware
/ Flat-panel displays
/ Set-top box
/ IP CAM
/ 5G base station & infrastructure
/ EV electric vehicle

TYPICAL PROPERTIES

PROPERTY DTT13-s UNIT TEST METHOD
Color Gray - Visual
Resin base Silicone - -
Viscosity 20000 Pa.s DIN 53018
Flow Rate 17 g/min By LiPOLY
Density 3.3 g/cm³ ASTM D792
Application temperature -60~180 °C -
Bond line thickness 200~3000 μm -
ROHS & REACH Compliant - -
THERMAL
Thermal conductivity 13.0 W/m*K ASTM D5470
Thermal impedance@10psi / 60°C 0.031 °C-in²/ W ASTM D5470
Thermal impedance@50psi / 60°C 0.024 °C-in²/ W ASTM D5470
