DCTP140-s
4.5 W/m*K
Fiberglass reinforced
DCTP140-s 玻纖導熱墊片是一種採用玻璃纖維布作為補強材料，與導熱矽相結合的導熱材料，具有高導熱性和出色的抗壓強度。導熱係數4.5W/m*K，厚度0.25~0.45mm。其高絕緣性和玻璃纖維材料增加了其結構的強度，使其具有耐切割性。 DCTP140-s是高扭力螺絲設定的最佳選擇。與高功率電子元件和散熱器的電氣隔離效果良好。
CATEGORY
FEATURES
/ Thermal conductivity:4.5 W/m*K
/ Excellent insulator
/ Re-workable
/ Fiberglass reinforced
SPECIFICATIONS
/ Roll form
/ Sheet form
/ Die-cut parts
TYPICAL APPLICATION
/ Power supplies
/ Motor controls
/ EV electric vehicle
/ Automotive electronics
/ 5G base station & infrastructure
Thermal Resistance vs. Pressure
TYPICAL PROPERTIES
| PROPERTY | DCTP140-s | TEST METHOD | UNIT |
|---|---|---|---|
| Color | Blue | Visual | - |
| Reinforced layer | Fiberglass | - | - |
| Thickness | 0.25 | ASTM D374 | mm |
| Density | 2.8 | ASTM D792 | g/cm³ |
| Hardness | 80 | ASTM D2240 | Shore A |
| Application temperature | -60~180 | - | ° C |
| ROHS & REACH | Compliant | - | - |
| THERMAL | |||
| Thermal conductivity | 4.5 | ASTM D5470 | W/m*K |
| Thermal impedance@20 psi | 0.357 | ASTM D5470 | °C-in²/ W |
| Thermal impedance@60 psi | 0.223 | ASTM D5470 | °C-in²/ W |
