矽型 · 導熱材料 ——
S-putty2-s
6.0 W/m·K
No Vertical Flow
S-putty2-s 是具有熱傳導係數：6.0W/m*K的導熱凝膠間隙填充材料，高變形量體，極低的熱阻值及低應力，可靈活性的適配間隙，兼具公差補償特性，可以克服類似導熱膏溢流、乾凅問題，可以搭配LiPOLY之putty專用智能機，自動化點膠作業生產的理想選擇。
CATEGORY
Thermal Putty
FEATURES
/ Thermal conductivity:6.0 W/m*K
/ Bond line thickness:100-1500µm
/ Designed to remove manufacturing tolerances
/ Does not produce stress on delicate components
/ No vertical flow
/ Dispensable for serial manufacture
/ For any high compression and low stress application
CONFIGURATIONS
/ Cartridges: 30ml, 55ml, 330ml
/ Bucket: 1kg, 25kg
TYPICAL APPLICATION
/ Between CPU and heat sink
/ Between a component and heat sink
/ High speed mass storage drives
/ Telecommunication hardware
/ Flat-panel displays
/ Set-top box
/ IP CAM
/ 5G base station & infrastructure
/ EV electric vehicle
TYPICAL PROPERTIES
| PROPERTY | S-putty2-s | UNIT | TEST METHOD |
|---|---|---|---|
| Color | Blue | - | Visual |
| Resin base | Silicone | - | - |
| Viscosity | 3500 | Pa.s | DIN 53018 |
| Flow Rate | 21 | g/min | By LiPOLY |
| Density | 3.3 | g/cm³ | ASTM D792 |
| Application temperature | -60~180 | °C | - |
| Bond line thickness | 100~1500 | μm | - |
| ROHS & REACH | Compliant | - | - |
| THERMAL | |||
| Thermal conductivity | 6.0 | W/m*K | ASTM D5470 |
| Thermal impedance@10psi / 60°C | 0.062 | °C-in²/ W | ASTM D5470 |
| Thermal impedance@50psi / 60°C | 0.053 | °C-in²/ W | ASTM D5470 |
